MW19PNW-4 - SATORI 7.5" MID-WOOFER WHITE

SB ACOUSTICS

$299.00


Calculate Shipping


SB ACOUSTICS Vented aerodynamic cast aluminium chassis for optimum strength and low compression. Proprietary cone material with EGYPTIAN PAPYRUS™ fibres made in-house. Soft low damping rubber surround for optimum transient response. Advanced BIMAX spider for improved linearity. Powerful optimized low distortion neodymium motor system. Non-conducting fibre glass voice coil former for minimum damping. Extended copper sleeve on pole piece for low inductance and reduced distortion. CCAW voice coil for reduced moving mass. Long life silver lead wires attached 180° apart for improved stability. Vented pole piece for reduced compression. High piston to chassis diameter ratio. Gasket and bolt hole protrusions for reduced coupling to speaker cabinet. Vented aerodynamic cast aluminium chassis for optimum strength and low compression Proprietary cone material with EGYPTIAN PAPYRUSTM fibres made in-house Soft low damping rubber surround for optimum transient response Advanced BIMAX spider for improved linearity Powerful optimized low distortion neodymium motor system Non-conducting fibre glass voice coil formerfor minimum damping Extended copper sleeve on pole piece for lowinductance and reduced distortion CCAW voice coil for reduced moving mass Long life silver lead wires attached 180° apartfor improved stability Vented pole piece for reduced compression High piston to chassis diameter ratio Gasket and bolt hole protrusions for reducedcoupling to speaker cabinet

(74406)

Order CodeMW19PNW-4
TypeMid-Woofer
Size7.5"
Price Typeeach
Power70Wrms
Coil39mmØ
Width187mmØ
QTY1
Impedance4O (Re 3.4O)
Depth90.2mm
Mag.0.15kg
Sens.91dB
Re3.4O
Qms4.02
Qes0.22
Qts0.21
Vas78.1L
Sd158cm²
Cms2.22mm/N
Fs32Hz
Mms16.7g
Zn4O
Le0.14mH
Rms0.7kg/s
Diam.191mmØ
SeriesSatori
Page8c
ManufacturerSB Acoustics
Prms70W
MaterialsPapyrus White
Impedance (Ohm)4 ohm
Power (RMS)51-100 Watt
Inch7.5
SKU 74406
Model # MW19PNW-4
Brand SB Acoustics
