NE19VTS-04 - VIFA 3/4" DOME NEODYMIUM TWEETER

$49.95
In Stock


Calculate Shipping


The Vifa NE product line of tweeters has leading-edge transducer technology packaged in cutting edge, stylistic designs. The surround fabric (and dome) has been woven from silk and coated for reproducing beautiful acoustics in the extended high end. Vifa’s finite element analysis designed high power, high performance, neodymium-iron-boron (NdFeB) motor provides high output in a small unit. Attractive Aluminium face plate and plastic protective grille. This new generation of tweeter offer compact, powerful, efficient level of advanced driver technology. Available in two types of dome material:

(35258)

Order CodeNE19VTS-04
TypeTweeter
Size0.75"
Price Typeeach
Power100Wrms
Freq.2500 Hz - 20000 Hz
Coil19.3mmØ
Width52mmØ
QTY1
Impedance4O (Re 2.7O)
Depth25mm
Mag.60g
Sens.88.57dB
Re2.7O
Qms3.4
Qes2.27
Qts1.36
Vas0.01L
Sd4.9cm²
Cms0.2229mm/N
Revc2.7 ohm
Fs743Hz
Mms0.21g
Zn4O
Le0.01 mH
F548
Fr2.5 K Hz - 20 K Hz
ManufacturerVifa
Pwr100 W System
Outer Dimensions53 mm (Overall Dia)
Prms100W
Impedance (Ohm)4 ohm
Power (RMS)51-100 Watt
Inch0.75

SKU 35258
Model # NE19VTS-04
Brand Vifa
Shipping Weight 0.0600kg
