MA1260 Multi-Zone 12 Channel Amplifier 60WPC
12 channels (6 stereo zones) in one convenient enclosure
Notify me when back in stock
Two common or BUS inputs feed audio signals from standard line-level audio sources to any or all channels. Each of the twelve channels has its own dedicated input and independent level adjustment to provide further flexibility. By simply flipping a single switch, two channels can be bridged to increase the total power output for that zone. This is helpful when extra power is needed in certain areas. Manual, automatic on/off, or triggered 12V input turn-on modes facilitate easy integration into automated systems. For quick and easy troubleshooting of the system, each pair of channels or zones has a bi-color LED to indicate its operational status.
Specifications: • Rated power output per channel: 65 watts RMS into 8 ohms, 89 watts RMS into 4 ohms • Bridged output: 130 watts into 8 ohms (8 ohm minimum) • Circuit topology: Class D • Signal to noise ratio: 100 dB A-weighted • Efficiency: 93% • Frequency response: 7.5 Hz to 48 kHz • Dimensions: 16.7" W x 4" H x 14.25" D (tabletop configurations) • Power requirements: 115/230 VAC, 50 Hz/60 Hz • Stand-by power rating: 115V 0.46W.
• 12 channels (6 stereo zones) in one convenient enclosure
• Efficient Class D design delivers superior audiophile sound quality and performance
• Independent and bus inputs provides unparalleled flexibility
• Bridgeable channel outputs provide additional power when needed
• Independent channel gain controls allow the output of each speaker to be perfectly matched
• Can be converted easily between rack-mount and tabletop configurations
• Installer-friendly setup and connections
|Unit of Measure||Each|
|Warranty - Parts||5 Years|
|Warranty - Labor||5 Years|
|Product Shipping Weight (lbs.)||40.0000|
|Amplifier Type||Multi-Zone Amplifiers|
|Power Output||per channel: 65 watts RMS into 8 ohms, 89 watts RMS into 4 ohms • Bridged output: 130 watts into 8 ohms (8 ohm minimum)|
|Power Output (RMS @ 70V) Range||--|
|Input Impedance||16.7K ohms|
|Signal-to-Noise Ratio||115 dB A-Weighted (1W, line input)|
|THD @ Rated Power||0.020% (8 ohms, 1W @ 1 kHz), 0.035% (4 ohms, 1W @ 1kHz)|
|Low Pass Adjustment||--|
|Frequency Response||7.5 – 48 Hz (+0/-3 dB)|
|Efficiency||93% (full power)|
|Stand-by Power Rating||0.46 W (115V)|
